REGO CB000504-B Cryogenic Pressure Builder Economizer Regulator for Bulk Vessels

REGO CB000504-B Cryogenic Pressure Builder Economizer Regulator for Bulk Vessels
REGO CB000504-B Cryogenic Pressure Builder Economizer Regulator for Bulk Vessels
REGO CB000504-B Cryogenic Pressure Builder Economizer Regulator for Bulk Vessels
REGO CB000504-B Cryogenic Pressure Builder Economizer Regulator for Bulk Vessels
Easy return of products within 14 days from the date of purchase without giving reasons

Application

CB504 series regulators maintain the pressure of cryogenic liquid within bulk vessels combining the pressure building and economizer function in one unit, with ½” npt inlet and outlet.

Features

  • All parts are copper alloy (brass), PTFE, and stainless steel— materials selected specifically for compatibility with cryogenic temperatures down to –320ºF. (–196ºC)
  • Pressure setting scale on bonnet cap aids in pressure adjustment.
  • Maximum inlet pressure of 400 psig (37.92 barg)
  • PTFE seat provides positive shut off at cryogenic temperatures
  • Compact design fits well in tight plumbing geometries
  • 100% factory tested
  • Cleaned per CGA G-4.1 for oxygen service
  • Suitable for argon, CO2, nitrogen, oxygen and LNG

Materials

  • Body Brass
  • Seat PTFE
  • Diaphragm Gasket PTFE
  • Bonnet Brass
  • Backcap Gasket Copper
  • Diaphragm Phosphor Bronze
  • Spring Stainless Steel
Diagram 2 REGO CB000504-B Cryogenic Pressure Builder Economizer RegulatorDiagram 1 REGO CB000504-B Cryogenic Pressure Builder Economizer Regulator
rego 10 years warrantyREGO CB000504-B Cryogenic Pressure Builder Economizer

CB504

Ordering Information

Part NumberInlet / Outlet Connections (F.NPT)Operating Range (psig)
CB000504-B 1/2" 100-200 psig (6.9-13.8 barg)
Producer
Product code
CB000504-B
