REGO CBH502-300 1/4” Pressure Builder / Economizer
REGO CBH502-300 1/4” Pressure Builder / Economizer
REGO CBH502-300 1/4” Pressure Builder / Economizer
REGO CBH502-300 1/4” Pressure Builder / Economizer

REGO CBH502-300 1/4” Pressure Builder / Economizer

14 days for easy returns
This product is not available in a stationary store
Safe shopping

Application

The regulator combines the function of Pressure Building and Economizer functions in one compact unit. Available in Chart and Taylor-Wharton piping geometries and a variety of pressure ratings.

Features

  • All parts are copper alloy (brass), PTFE and stainless steel materials selected specifically for compatibility with cryogenic temperatures down to -320° F. (–196ºC)
  • PTFE seat helps assure a positive shut-off at cryogenic temperatures down to -320° F. (–196ºC)
  • High and low pressure builder/economizers are the same compact size designed to fit in close quarters.
  • Interchangeable with existing cryogenic regulator units.
  • Inlet screen helps prevent foreign material from entering the regulator.
  • Locknut is provided to maintain adjusting screw setting.
  • Maximum inlet pressure of 550 psig (37.9 barg)
  • Cleaned for oxygen service per CGA G-4.1
  • 100% Factory Tested.
  • Suitable for argon, CO2, nitrogen and oxygen.

Materials

  • Body Brass
  • Seat Disk  PTFE
  • Gaskets PTFE & Copper
  • Bonnet Brass
  • Diaphragm Bronze
  • Springs Stainless Steel
Cryogenic ¼” Combination Pressure Builder Economizer CBH502 CBC502 SeriesCombination Pressure Builder/Economizer CBH502 & CBC502 Series
rego 10 years warrantyPressure Builder/Economizer CBH502 & CBC502 Series

CBH502Series

Ordering Information

Part NumberInlet / Outlet Connections (F.NPT)"A""B""C""D"Factory Pressure Setting (psig)Operating Range (psig)
CBH502-015 ¼" ¼" 1.97” 2.89” 1.19” 15 psig (1.03 barg) 10-60 psig 0.7 - 4.1 barg
CBH502-125125 psig (8.6 barg) 50 - 175 psig 3.4 - 12.1 barg
CBH502-300300 psig (20.7 barg)50 - 175 psig 3.4 - 12.1 barg
CBH502-315315 psig (21.7 barg)50 - 175 psig 3.4 - 12.1 barg
CBH502-325325 psig (22.4 barg)50 - 175 psig 3.4 - 12.1 barg
CBH502-350350 psig (24.1 barg) 150 - 350 psig 10.3 - 24.1 barg
CBC502-01515 psig (1.03 barg)  10-60 psig 0.7 - 4.1 barg
CBC502-125125 psig (8.6 barg)  50 - 175 psig 3.4 - 12.1 barg
CBC502-300300 psig (20.7 barg)  50 - 175 psig 3.4 - 12.1 barg
CBC502-325325 psig (22.4 barg)  50 - 175 psig 3.4 - 12.1 barg
CBC502-350350 psig (24.1 barg)  150 - 350 psig 10.3 - 24.1 barg
Technical parameters
Brand
Product code
CBH502-300
