Application
Retrofit kits are be used to convert the 9450 and 9460 series short stem shut off valves into extended stem style. The conversion can be done without removing the valve from your system. Available in two stem lengths. All kits are oxygen cleaned and packaged per CGA G-4.1.
Materials
- Body Brass
- Seat Disc PCTFE
- Stem Seal Gasket PTFE
- Handwheel Aluminum
- Packing l PTFE
- Stem Stainless Steel
Ordering Information
Part Number | Stem Length A | Style |
---|---|---|
ES8450R | 4” | Extended Stem, Std. Bonnet, Manual Packing |
BK9450R | 6.5” | Extended Bonnet and Stem, Spring Loaded Packing |
