REGO ES8452 ¼” FNPT Cryogenic Shut-Off Valves - Extended Stem

REGO ES8452 ¼” FNPT Cryogenic Shut-Off Valves - Extended Stem
REGO ES8452 ¼” FNPT Cryogenic Shut-Off Valves - Extended Stem
REGO ES8452 ¼” FNPT Cryogenic Shut-Off Valves - Extended Stem
REGO ES8452 ¼” FNPT Cryogenic Shut-Off Valves - Extended Stem
Easy return of products within 14 days from the date of purchase without giving reasons

Application

For use as a trycock valve or hose drain valve on cryogenic tanks, or as a use, liquid fill, or vent valve on mini-bulk cryogenic tanks. These valves can be used also for other cold gas applications requiring extended stem valves as LNG fueling.

Features

  • Union bonnet
  • One piece stainless steel stem
  • Conical seat design.
  • Maximum working pressure is 600 psig (42 barg).
  • Working temperature is –320°F to +165°F. (-196ºC to 74ºC)
  • Cleaned for oxygen service per CGA G-4.1.
  • Working temperature range is -320°F to +165°F. (-196ºC to +74ºC)
  • 100% Factory Tested

TES8450 Series specific feature:

  • Grafoil® packing
  • Approved by PED and TPED

ES8450 Series specific feature:

  • Manual torque compression packing.

BK9450 and BK9470 Series specific feature:

  • Extended bonnet and spring loaded packing.

BK9470 Series specific feature:

  • 304 St. Stl Tube brazed into both ends.

Materials

  • Body Brass
  • Bonnet Brass
  • Seat Disc PCTFE
  • Bonnet Gasket PTFE
  • Handwheel Aluminum
  • Packing PTFE
  • Stem Stainless Steel
  • Packing(TES) Grafoil

BK 9470 Series

rego 10 years warranty

ES8450 & TES8450 Series Extended Stem ValvesES8450 Series

BK9450 & BK9470 Series Extended Bonnet ValvesBK9450 Series

Ordering Information

Part NumberInlet/Outlet ConnectionsHeight "A"Body Width "B"Width with Tube "C"Cv Factor
ES8452 ¼” FNPT 4.2” 2.5” 0.70
TES8452
ES8453 3/8” FNPT 1.10
TES8453
ES8454 ½” FNPT
TES8454
BK9452 ¼” FNPT 6.5” 0.70
BK9453 3/8” FNPT 1.10
BK9454 ½”FNPT
BK9453FA 5/8” OD tubing x 3/8”FNPT 4.0”
BK9475A 5/8” OD tubing both ends 5.5”
Producer
Product code
ES8452
