System monitorowania RENOGY ONE Core

RENOGY ONE Core | Renogy UK

• Cloud-based energy monitoring worldwide. • 24/7 energy analysis on multiple devices. • Built-in RV leveling sensor for stabilityand comfort. • Connect smart accessories for home automation. • Easy installation with horizontal bubble.

Specifications

• Operating Voltage:8-60 VDC (5 VDC for USB Type-C)
• Power Consumption at 12V:Operating, WiFi On, 100% illumination: 3.2 W
• Operating, WiFi On, 50% illumination: 2.4 W
• Operating, WiFi On, 0% illumination: 1.9 W
• Off, logger still active : 1.5 W
• Communication:Wi-Fi (IEEE 802.11b/g/n 2.4 GHz)
• Bluetooth LE and Bluetooth Mesh
• Zigbee 3.0 (IEEE 802.15.4)
• RS-485
• Touch Screen: 4" (480 x 480p)
• Leveling Range and Accuracy:±89°, 0.1°
• Model: RSHGWSN-W02W-G1
• Operating Temperature:-4℉ to 158℉ (-20℃ to 70℃)
• Operating Humidity:0% to 95% RH
• Operating Altitude:Less than 5000m above sea level
• Installation:Flush mount or place on a table
• Dimensions:4.17 x 4.17 x 1.05 in (106 x 106 x 26.6 mm)
• Weight:0.28 lb (128g)
• Certification:CE, FCC, RoHS, TSCA, BQB, IC-ID
• Warranty:2 years
