Fuse holder 6-way for MEGA fuse

• Max. current 250 A
• Max. Voltage 70 VDC
• Terminal diameter 5/16 inch / 8 mm
• Terminal height 0.67 inch / 14 mm
• Terminal material Galvanised steel
• Hex nut material Galvanised steel
• Recommended torque 60 lbf·inch / 7 N·m
• Busbar strip material Tin-plated copper (3 x 18 mm)
• Base material ABS, black, UL 94 V-0
• Cover material Clear Polycarbonate, UL 94 HB
• Weight 1 lb / 0,45 kg
• Dimensions (hxwxd) (with cover) 2.0 x 7.2 x 3.5 inch 50.9 x 181.5 x 88 mm
