Lithium Battery Power Set

Lithium Battery Power Set

The Lithium Battery Power Set is the optimal combination for motorhomes or vans. Use the set to switch to lithium batteries or to equip your new vehicle with them right from the start. The combination of the individual components guarantees constantly full capacity and safe operation in all climate zones and all year long.

The set is designed in such a way that it works as an independent system, but can also be connected in parallel to existing on-board electronics. It consists of a lithium RV battery MT Li 85, MT Li 105 or MT Li 120 in combination with a charger/b>ooster combination and a battery computer (MT iQ Basic). All devices were developed by Büttner Elektronik and are optimally geared to each other. The charger/b>ooster combination unit (BCB 25/20) supplies the battery with charging current (20 A) if there is a 230 V mains supply and automatically switches to booster charging (25 A) while driving. In both charging situations, the device receives information directly from the lithium battery, so that it can optimally charge it. Additionally, the battery computer monitors the battery and displays battery capacity (in % and Ah), current consumption (A) and the remaining time inside the vehicle.

The set includes a ready-to-plug-in installation cable set for the battery computer as well as a cable set for integrating the charger/b>ooster combination unit into existing on-board electronics.

We would like to point out the procedure for taking back used batteries: According to the "Ordinance on the Return and Disposal of Used Batteries"

• rechargeable batteries and batteries must never be disposed of with normal residual waste.
• Batteries containing hazardous substances must be returned to a distributor or to take-back centres set up for this purpose by the public waste disposal authorities.
