Application
The most popular Female Vent Coupler for dispensers of LNG. Safe and easy operation.
Features
- Over 100,000 in service worldwide
- LNG vent/fill connection (male). Handles both LNG Vent Gas and LNG Liquid
- Max internal pressure 300 psig /20.7 barg (while fueling)
- Max system pressure 550 psig /38 barg (static)
- Temperature range -350°F to 150°F ( -212°C to 65°C).
- 100% pressure tested
Materials
- Female Housing : Stainless Steel 316L
- Seal Retainer : Stainless Steel 303
- Seal ASSY : TFE/Viton
- Seal : TFE
- Poppet : Stainless Steel 303
- Seal Poppet : PCTFE
- Spring ; Stainless Steel 301/302
FQD10 Series
Ordering Information
Part Number | Inlet Connection |
---|---|
FQD100604N | 90° Tubing. ⅝" 45° SAE Fitting (CGA 440) |
FQD100602N | ⅝" 45° SAE Fitting (CGA 440) Short Straight Handle |
FQD100603N | ⅝" 45° SAE Fitting (CGA 440) Long Straight Handle |
