REGO CBC502-325 1/4” Pressure Builder / Economizer
Application
The regulator combines the function of Pressure Building and Economizer functions in one compact unit. Available in Chart and Taylor-Wharton piping geometries and a variety of pressure ratings.
Features
- All parts are copper alloy (brass), PTFE and stainless steel materials selected specifically for compatibility with cryogenic temperatures down to -320° F. (–196ºC)
- PTFE seat helps assure a positive shut-off at cryogenic temperatures down to -320° F. (–196ºC)
- High and low pressure builder/economizers are the same compact size designed to fit in close quarters.
- Interchangeable with existing cryogenic regulator units.
- Inlet screen helps prevent foreign material from entering the regulator.
- Locknut is provided to maintain adjusting screw setting.
- Maximum inlet pressure of 550 psig (37.9 barg)
- Cleaned for oxygen service per CGA G-4.1
- 100% Factory Tested.
- Suitable for argon, CO2, nitrogen and oxygen.
Materials
- Body Brass
- Seat Disk PTFE
- Gaskets PTFE & Copper
- Bonnet Brass
- Diaphragm Bronze
- Springs Stainless Steel
CBH502Series
Ordering Information
| Part Number | Inlet / Outlet Connections (F.NPT) | "A" | "B" | "C" | "D" | Factory Pressure Setting (psig) | Operating Range (psig) |
|---|---|---|---|---|---|---|---|
| CBH502-015 | ¼" | ¼" | 1.97” | 2.89” | 1.19” | 15 psig (1.03 barg) | 10-60 psig 0.7 - 4.1 barg |
| CBH502-125 | 125 psig (8.6 barg) | 50 - 175 psig 3.4 - 12.1 barg | |||||
| CBH502-300 | 300 psig (20.7 barg) | 50 - 175 psig 3.4 - 12.1 barg | |||||
| CBH502-315 | 315 psig (21.7 barg) | 50 - 175 psig 3.4 - 12.1 barg | |||||
| CBH502-325 | 325 psig (22.4 barg) | 50 - 175 psig 3.4 - 12.1 barg | |||||
| CBH502-350 | 350 psig (24.1 barg) | 150 - 350 psig 10.3 - 24.1 barg | |||||
| CBC502-015 | 15 psig (1.03 barg) | 10-60 psig 0.7 - 4.1 barg | |||||
| CBC502-125 | 125 psig (8.6 barg) | 50 - 175 psig 3.4 - 12.1 barg | |||||
| CBC502-300 | 300 psig (20.7 barg) | 50 - 175 psig 3.4 - 12.1 barg | |||||
| CBC502-325 | 325 psig (22.4 barg) | 50 - 175 psig 3.4 - 12.1 barg | |||||
| CBC502-350 | 350 psig (24.1 barg) | 150 - 350 psig 10.3 - 24.1 barg |
