Indoor HydroCab

Indoor HydroCab

Indoor HydroCab: The high quality 19” cabinet system is particularly suitable for yourindividual indoor H2 application and includes u p to five stackable El 2.1 electrolysers and one
dryer.
Several cabinets can be used to build larger systems.

Specifications

• IP rating: IP20 indoor cabinet
• Cabinet outside dimensions: W × D × H in mm = 800 × 800 × 2200
• Available size inside: 42 U
• Cabinet weight (empty): 180 kg
• Surrounding free space requirements:
• Front: 1.5 m - for working access and airflow Back: 0.5 m - for airflow
• Side, top and bottom: no minimum distance required.
• Cooling: Passive. Airflow for stack cooling is blown for each module individually from front to back.
• Location of connections and piping: All piping and electrical connections are located in the front of the machine. Power, water and hydrogen connections are located at the bottom of the back of the cabinet.
• Filters: No filters needed
• Ambient temperature: 5 – 45 °C
• Ambient humidity: 20 – 95 %, non-condensing
