LILIE diaphragm pump LP403 ClassicSerie 12 V, 10.6 l/min, 2.1 bar - for camper drinking water
ID produktu: 29249
- LILIE LP403 ClassicSerie 3-chamber 12 V diaphragm pump for drinking water: 10.6 l/min, cut-off 2.1 bar (adjustable 1.75-3.2 bar), dry self-priming up to 3.1 m, up to 4 taps.
The LILIE LP403 from the ClassicSerie is a 3-chamber 12 V diaphragm pump for drinking water systems in campers, caravans and boats. It delivers up to 10.6 l/min, switches off at 2.1 bar and back on at 1.8 bar. It supplies up to 4 taps. It is part of the LILIE WeißGELB drinking water system.
Key information
- 3-chamber 12 V diaphragm pump
- flow rate 10.6 l/min
- cut-off 2.1 bar (adjustable 1.75-3.2 bar), restart 1.8 bar
- max. current 4.0 A
- dry self-priming up to 3.1 m, can run dry
- up to 4 taps
- check valve in each head, rated above 13 bar
- weight 1.8 kg, dimensions 210 x 129 x 114 mm
Before you order
Materials: TPE membrane, EPDM/POM valves, PP housing. Supplied with pump, 2 screw-on hose tails for 10 mm hose and manual. 2-year manufacturer warranty. Use the cable cross-section and fuse specified in the manual.
Photos
Related products
- LILIE LP204 ClassicSerie pump 7 l/min
- LILIE LP209 ClassicSerie pump 9 l/min
- LILIE LP061 ClassicSerie pump 10 l/min
- quiet LILIE SoftSerie LP4142 pump
Technical data
| Parameter | Value |
|---|---|
| Manufacturer | LILIE |
| Series | ClassicSerie |
| Model | LP403 |
| Type | 3-chamber diaphragm pump |
| Voltage | 12 V |
| Flow rate | 10.6 l/min |
| Cut-off pressure | 2.1 bar (adjustable 1.75-3.2 bar) |
| Restart pressure | 1.8 bar |
| Max. current | 4.0 A |
| Suction lift | 3.1 m |
| Taps | up to 4 |
| Materials | TPE membrane, EPDM/POM valves, PP housing |
| Dimensions | 210 x 129 x 114 mm |
| Weight | 1.8 kg |
| Included | pump, 2 hose tails 10 mm, manual |
| Warranty | 2 years |
Questions and answers
How many taps can it supply?
Up to 4 taps.
Can the pump run dry?
Yes, it is dry self-priming and can run dry.
Can I change the cut-off pressure?
Yes, between 1.75 and 3.2 bar, factory set to 2.1 bar.
Manufacturer
LILIE GmbH & Co. KG, Heinrich-Hertz-Straße 30, 74354 Besigheim, Germany.
ID produktu
29249
Brand
Gross weight
2000 g
Pressure
2.1 bar
Required height
3.1 m
Wymagana objętość
10.6 l/min
Cable length
0.5 m
Width
12.9 cm
Height
11.4 cm
Nominal power
48 W
Nominal voltage
12 V
Rated current
4 A
Net weight
1800 g
Max package dimension
28 cm
Min package dimension
12 cm
Middle package dimension
14 cm
Drinking water
Yes
Variant
2.1 bar | 10.6 l/min
