GasBank DISH to M10 LPG filling adapter with filter GB-F-05 - replaceable sintered bronze filter

GasBank GB-F-05 is an LPG filling adapter with a DISH coupling and a built-in replaceable sintered bronze filter. Screw its male M10x1.5 thread into a filling point with a female M10 thread, and the gas from the pump passes through the filter before it enters the system. The DISH plate has a female M10 thread for ACME, BAYONET or EUROCONNECTOR M10 adapters - so you can fill through the filter outside DISH countries too.

What it is for

• filling LPG from DISH nozzles, standard e.g. in Poland, France and Italy
• the filter stops contaminants in the gas before they reach the tank and the system
• the female M10 thread in the DISH plate takes M10 adapters for other couplings
• the male M10 thread with seal screws into a filling point with a female M10 thread

Where the DISH coupling is used

• Poland, Czech Republic, Slovakia, Hungary, Lithuania, Latvia, Estonia
• France, Italy, Greece, Malta, San Marino
• Croatia, Slovenia, Serbia, Bosnia and Herzegovina, Montenegro, North Macedonia, Albania, Kosovo
• Romania, Bulgaria, Moldova, Ukraine, Turkey, Sweden
• alongside other couplings: Austria, Switzerland, Denmark, Norway, Portugal
• in ACME, BAYONET or EUROCONNECTOR countries screw the matching M10 adapter into the plate

Filter

• sintered bronze filter element
• working temperature -20 to 120°C, working pressure 3000 kPa (30 bar)
• the element is replaceable and can be cleaned
• the arrow on the body shows the gas flow direction - from the nozzle to the filling point
• check the filter regularly, especially after filling at unfamiliar stations

Fitting and filling

• remove the filler cap and screw in the adapter by its male M10 thread so that the seal sits evenly
• if the nozzle is not DISH, screw an M10 adapter with the right coupling into the plate
• connect the nozzle and fill according to the station rules
• after filling, disconnect the nozzle, unscrew the adapter if needed and refit the filler cap

Safety

• the adapter is intended for LPG
• check the seal and threads before each use
• do not fill if you smell gas or the connection leaks
• filling rules differ between countries - check the rules of your destination before travelling

Matching GasBank products

• ACME M10 filling adapter (GB501)
• BAYONET M10 filling adapter (GB502)
• EUROCONNECTOR M10 filling adapter (GB503)
• Set of three M10 adapters for all of Europe
• DISH M10 filling adapter (GB500)
• Service hose for an M10 filling point
• Pouch for 1 DIN or 3 M10 adapters
• Adapter case with 3 compartments

Technical data

Manufacturer

GasBank (Carbon Zorro Sp. z o.o.), ul. Humańska 8, 02-789 Warszawa, Poland.
